Advantech 1 Port GbE PoE to SFP Fiber Media Converter
Deskripsi
| Category | Attribute | Value | |
| Power | Power Connector Type | 2-pin removable screw terminal | |
| Power | Power Consumption | 34W | |
| Power | Power Operating Current | 0.07A @48Vdc(system) | |
| Environment | Relative Humidity | 10~95% | |
| Environment | Temperature (Operating Range) | -40 ~ 75°C (-40 ~ 167°F) | |
| Environment | Temperature (Storage Range) | -40 ~ 85°C (-40 ~ 185°F) | |
| Mechanism | Dimensions (W x H x D) | 36.7 x 108.4 x 103.5 mm | |
| Mechanism | Enclosure (Metal) | Metal | |
| Mechanism | IP Rating | IP31 | |
| Mechanism | Mounting | DIN-rail, Wall | |
| Mechanism | Weight | 0.45 kg (1.0 lb) | |
| Ethernet Communication | Fiber Transmission Distance | Up to 110 km | |
| Ethernet Communication | RJ-45 Transmission Distance | 100 m | |
| Switch Properties | Jumbo Frame | 10K bytes | |
| Switch Properties | Switch Fabric Speed | 1.0Gbps | |
| Certification | EMC | CE, FCC | |
| Certification | EMS | EN 61000-4-2 (Level 3), EN 61000-4-3 (Level 3), EN 61000-4-4 (Level 3), EN 61000-4-5 (Level 3), EN 61000-4-6 (Level 3), EN 61000-4-8 (Level 3) | |
| Certification | Ethernet Standard | IEEE 802.3, 802.3u, 802.3x, 802.3ab, 802.3af/at | |
| Certification | Freefall | IEC 60068-2-32 | |
| Certification | Safety | UL508, Class 1 Division 2 | |
| Certification | Shock | IEC 60068-2-27 | |
| Certification | Vibration | IEC 60068-2-6 | |
| MTBF | Method | Telcordia(Relax), GB | |
| MTBF | Time | 743,594 hours | |
| Warranty | Warranty Period | 5 years | |
| PoE Information | PoE Port Number | 1 |
